Hard Chrome Plated Piston Rod
Product Details:
Hard Chrome Plated Rod and hardened hard plated chrome bars are designed to meet your specific needs for piston rod material in Hydraulic and Pneumatic Cylinders and other applications
| Material | EN-8(D)/CK45/ EN-9 / EN-19 /EN-24 or as per customer requirement |
| Standard Size | 16mm to 100mm. above 100mm can be order |
| Standard Length | Cut to customer length up to 7000mm |
| Hard chrome plating thickness | 30 to 35 micron |
| Surface Roughness | 0.2 RA |
| Surface Hardness | 60 HRC + 2 |
| Chrome surface hardness | 850 to 1000 HV |
| Straightness | 0.1 per meter max. |
| Chrome layer micro hardness | Min. 900HV0.1 |
| OD Tolerance | f7/f8/g6 |
Description
Hard Chrome Plated Rod and hardened hard plated chrome bars are designed to meet your specific needs for piston rod material in Hydraulic and Pneumatic Cylinders and other applications. Most advanced techniques of surface removal, polishing and hard chrome plating are used in manufacturing the above bars.
Hard Chrome plated bar is a chromium-plated Rod product used primarily as piston rod material in standard hydraulic and pneumatic applications
